UL20167 Multi-Conductor hmanga invenna Cable

Inquiry thawn rawh .
UL20167 Multi-Conductor hmanga invenna Cable
Kimchang
UL-certified tui tlak lohna cable
Antioxidant tha tak a nei
Ultra Wide Temperature Range a ni
Cut awlsam tak a ni
Insulation performance tha tak a ni
Thil siam zawng zawng hi boruak tichhe lo vek a ni
Quotation rang leh awlsam tak
UL certification zawm tur a ni
Thil mamawh bik i neih chuan min zawt mai thei
Bithliahna
UL Cable hmanga siam a ni
Share to
Hrilhfiahna

UL20167 Multi-Conductor hmanga invenna Cablechu UL-certified waterproof cable a ni a, UL758 leh UL1581 standard zawm a ni. Conductor hi tin-plated copper wire a ni a, PVC insulation hmanga khuh a ni. Temperature resistance range -20℃atanga 105℃thleng a nei a ni. UL VW-1 leh CSA FT1 flame retardant test a paltlang tawh a, RoHS environmental requirement a zawm bawk. Multi-core design nen a inmil a, electronic leh electrical equipment-a internal wiring atan hman a ni ber.



Nihphung


  • Insulation:PVC a ni

  • Conductor:Oxygen-Free Copper (OFC) 99.96%~99.99% a ni a, a man pawh a tlawm hle.

  • Rated temperature:105℃a ni

  • Rated voltage:300V a ni

  • Electrical leh electronicquipment chhunga inzawmna atan hman thin

  • UL VW-1 & CSA FT1 Vertical flame test a paltlang

  • A hmanna tur standard: UL758,UL1581

product-545-545



Dilna


Damdawi lam electronic hmanrua lam hawi

Portable medical devices, electrocardiogram monitor leh ultrasound diagnostic instrument tenauah te chuan UL20167 Multi-Conductor Shielded Cable hmangin internal circuit board te chu probes, display leh component dangte nen inzawm tir a ni. Medical devices hian himna leh stability atan mamawh sang tak tak a nei a. He cable-a boruak tichhe lo thil hian damdawi hmanrua atana non-toxic standards a zawm a, a waterproof property hian hmanrua disinfection laiin liquid contact chu a tuar thei a ni.

Consumer electronics lam hawi a ni

Smart home device-ah chuan UL20167 Multi-Conductor Shielded Cable hi smart speaker, floor cleaning robot, leh smart camera te ang chi device-te tana core internal wiring a ni. Entirnan, floor cleaning robot main board leh a motor leh sensor inkar wiring-ah hian he cable chi hi hman a ni fo thin. A waterproof property hian a tihfai laiin boruak hnim a tuar thei a, a flame retardancy hian short circuit a awm chuan device himna a tichiang thei a, multi-core design hian power leh signal transmission line a thlunzawm thei a, internal space a humhim thei bawk.

UL20167 Multi-Conductor Shielded Cable
UL20167 Multi-Conductor Shielded Cable

Industrial control leh automation lam hawi a ni

Industrial automated production line-a PLC controller, sensor leh actuator inkara short-line connection-ah hian UL20167 Multi-Conductor Shielded Cables hman tam ber a ni. Entirnan, food packaging production line-ah chuan hmanrua te chu tihfai fo a ngai a ni. He cable hian waterproof property a neih avangin tihfai laiin tui vapor lut lo turin a veng thei a, production line hmanrua hnathawh avanga temperature inthlak danglamna pawh a tuar thei a, chu chuan line fault avanga machine downtime hlauhawmna a ti tlem thei bawk.

Automotive electronics lam hawi a ni

Car chhunga electronic system, in-car navigation, central control screen, leh reverse camera te pawh UL20167 Multi-Conductor Shielded Cables hmangin wire theih a ni bawk. Car chhungril boruak hi a buaithlak hle a, nipui leh thlasik inkarah boruak lum leh vawt a inang lo ( thlasik laiin boruak lum leh vawt hniam ang chi), chubakah lirthei khalh laiin vibration a awm bawk. Heng dinhmunte hian cable-a temperature resistance leh mechanical property-ah thil khauh tak a siam a ni. He cable hian heng dinhmunte hi a nghetin a insiamrem thei a ni.



Ruangam



UL20167 Multi-Conductor Shielded Cable





Product chungchang sawifiahna





Part No. Conductor a ni Cores te pawh a awm

Insulation Thick a ni

(mm) a ni.

Bungrua Braild siamna a ni Kawrlum
AWG a ni

A sak dan (No./mm) 1.1.

DIA.(mm) a ni. A thuk(mm) a ni. Dia.(mm) a ni.
UL20167 a ni 30 7/0.10 0.3 2 0.23 Al-Myiar a ni 16/40.10 0.76 3.8
3 16/4/0.10 3.9
4 16/5/0.10 4.2
5 16/5/0.10 4.4
6 16/6/0.10 4.6
7 16/6/0.10 4.6
8 16/7/0.10 4.9
9 16/7/0.10 5.2
10 16/7/0.10 5.5
28 7/0.127 0.38 2 0.23 16/5/0.10 0.76 4
3 16/5/0.10 4.5
4 16/60.10 4.5
5 16/6/0.10 5
6 16/6/0.10 5
7 16/6/0.10 5.5
8 16/7/0.10 5.5
9 16/8/0.10 5.5
10 16/8/0.10 6
26 7/0.16 0.48 2 0.23 16/5/0.10 0.76 4.5
3 16/5/0.10 5
4 16/6/0.10 5
5 15/6/0.10 5.5
6 16/6/0.10 5.5
7 16/6/0.10 5.5
8 16/7/0.10 6
9 16/8/0.10 6
10 16/80.10 6.5
24 11/0.16 0.61 2 0.23 16/5/0.10 0.76 4.5
3 16/5/0.10 5
4 16/6/0.10 5
5 16/6/0.10 5.5
6 16/6/0.10 6
7 16/6/0.10 6
8 16/7/0.10 6
9 16/8/0.10 6.5
10 16/8/0.10 6.5
22 17/0.16 0.76 2 0.23 16/60.10 0.76 4.8
3 16/6/0.10 5
4 16/7/0 10 5.4
5 16/8/0.10 5.8
6 16/7/0.12 6.2
7 16/7/0.12 6.2
8 16/8/0.12 6.6
9 24/60.12 7.2
10 24/6/0.12 7.5
20 26/0.16 0.94 2 0.23 16/7/0.10 0.76 4.8
3 16/7/0.10 5.1
4 16/8/0.10 5.5
5 16/8/0.12 5.9
6 24/6/0.12 6.4
7 24/6/0.12 6.4
8 24/6/0.12 6.8
9 24/7/0.12 7.4
10 24/7/0.12 7.9
18 41/0.16 1.18 2 0.23 16/8/0.10 0.76 5.5
3 16/8/0.12 5.7
4 16/8/0.12 6.2
5 24/6/0.12 6.7
6 24/6/0.12 7.5
7 24/6/0.12 7.5
8 2417/0.12 7.8
9 24/8/0.12 8.5
10 24/8/0.12 9.2





UL Certificate pek a ni



UL-CA-2326935-0
UL-US-2331368-0001
UL-2326935-0
UL-2331368-0



Production Market ah hian thil siam chhuah a ni


UL20167 Multi-Conductor Shielded Cable

Kan company hian international brand hmingthang- tam takah components a supply thin. Customer te wire leh cable mamawh hrang hrang atan solution kan pe thei a ni. Kan market lian ber berte chu: United States, United Kingdom, Germany, Turkey, Russia, Dubai, Iran, Japan, Philippines, Malaysia, Singapore, Thailand, Brazil, Mexico, Australia, leh a dangte a ni.

pakhat-stop solution

professional team te an ni

sang

nihphung



Kan Product hi a ni



Wire leh cable siamtu professional kan ni a, Automotive wire, Electronic wire, Silicon Rubber wire, Power cable, PVC cable, XLPE cable, Coiled cable, Sensor cable, Industrial Automation wire, Locomotive cable, New Energy cable...etc.

UL1032 Solar PV Battery High temperature resistant Wire
Coiled cable
PVC Insulated Electrical Wire
UL20167 Multi-Conductor Shielded Cable
UL20167 Multi-Conductor Shielded Cable
PVC Insulated Electrical Wire
High temperature resistant Wire
Solar PV Battery Wire

FAQ



Q: Eng chi packaging nge i pek theih ang?

A: Roll-type, thing reel, leh pallet packaging te kan pe thin. Packaging mamawh bik i neih chuan i tan solution chu kan duh angin kan siamsak thei che a ni.

Q: I thil siam quality hi a chiang em?

A: Ni e, kan workshop-ah hian Brand-new leh Advanced Machine leh Test Equipment kan dah a ni. Chu bakah kan hnathawkte hi Professional Technician an ni bawk. Kan thil siam chhuah dan leh quality hi international standard leh customer te mamawh ang chiah a ni.

Q: Electronic wire & cables sample order ka nei thei ang em?

A: Ni e, quality test leh check turin sample order kan lawmpui hle. Mixed sample hi pawm theih a ni. Free sample thenkhat pawh a awm bawk.

Q: Electronic wire & cables te tan guarantee i pe em?

A: Ni e, kan thil siamte hi kum 1 chhung warranty kan pe a.
